PMPPC60-100

44 PMPPC60-100 TECHNICAL DATA INTELLIGENT VARIABLE SPEED PUMP HIGH PERFORMANCE The characteristics of the product: With the world's last frequency conversion technology, built-in digital intelligent technology and permanent magnet brushless synchronous motor technology, which casted a high efficiency, economy, intelligent, quiet running, more reliable. World wide using under 50/60hz with same performance. Complete function, easy operation and clear menu; With power factor correction; Use extremely high performance permanent magnet brushless synchronous motor, lower vibration and noise, more efficiency, longer life ; The controller is equipped with a 2.4 inch lcd and silicone keypad, convenient programming; Built-in diagnostic function, run-dry,overheating, voltage fluctuation, freezing and over-current protection; Special appearance design,better cooling,stalbe running. Working environment: Well ventilated to facilitate heat dissipation. Working environment temperature: -10℃〜+40℃. 1.5 1.1 100% 80% 50% HP kW RPM Model POWER SUPPLY SPEED POWER CONSUMPTION MAX PMPPC60-100 208-240V/50/60Hz 3450 2760 1725 800-1700W 500-900W 150-300W 16 STYPE Imax 7.5A WIFI IE4
